Diamondcuttingwire鑽石切割線介紹Diamondcuttingwire
[沛星光電]鑽石線鑽石切割線鑽石線鑽石切割線鑽石線鑽石切割線鑽石線鑽石切割線
Diamond cutting wire 鑽石切割線介紹
鑽石切割線是由我們自己的研究和開發新產品。產品的質量已經達到了世界領先水平。產品用於支持手動切割耗材,線,多線切割機,它可以取代光磨料的切割工藝。為了獲得精確的切削各種類型的人工晶體,陶瓷,石英玻璃,單晶矽,多晶矽,藍寶石和特殊的金屬材料等。
技術參數:
1。直徑:0.12〜0.36毫米,直徑偏差≤0.01毫米
2。總線材質:高強度鋼線切割
3。粒度,金剛石:5微米到60微米,我們可以根據客戶的要求設計
4。拉伸強度:3200〜3400Mpa
5。線長:我們可以根據用戶的要求加工
Diamond cutting wire is a new product by our own research and development. The quality of product has reached the world leading level. Products are used in cutting supplies supporting the manual, in-line, multi-wire cutting machines, it can replace the cutting process of light abrasive. For precise cutting various types of artificial crystal, ceramic, quartz glass, monocrystalline silicon, polycrystalline silicon, sapphire and special metal materials and so on.
Technical parameters:
1. Diameter: 0.12 to 0.36mm, diameter deviation ≤ 0.01mm
2. Bus Material: high strength steel wire cutting
3. Grit size of diamond: 5μm to 60μm, we can design according to the customer's requirements
4. The tensile strength: 3200 to 3400Mpa
5. Wire length: we can processing according to user's requirements
